Installing For Android 6 Axis GRBL CNC Gcode sender

Installing For Android 6 Axis GRBL Gcode sender

before USE 6 Axis Please Learn 3 Axis Android GRBL CNC Controller First For How To Connect Bluetooth Hardware




1.Download Firmware 6 Axis GRBL Gcode sender For Arduino ATMega2560


2.Download a program for flashing (Windows: XLoader, Mac OS X: HexUploader, Linux: Easy Flash script) also from github and extract the file.


Started running the Loader program. Input your , processor (Arduino ATmega2560), comm port and the destination of where you put the saved Firmware

Should start and be finished in few seconds with a message Finish

Close the Loader program and open your grbl controller and connect at Baud rate 9600. You should see that is has 0.9g load


3.Config Machine Parameter using settings from grbl's wiki for configuring them.


4.Downlopad Android 6 Axis GRBL Gcode sender @ Play Store


5.Hardware Configuration






ATMEGA 2560 Pin Out Configuration


 X_STEP_BIT                       MEGA2560 Digital Pin 22

 Y_STEP_BIT                       MEGA2560 Digital Pin 23

 Z_STEP_BIT                       MEGA2560 Digital Pin 24

 A_STEP_BIT                       MEGA2560 Digital Pin 25

 B_STEP_BIT                       MEGA2560 Digital Pin 26

 C_STEP_BIT                       MEGA2560 Digital Pin 27



 X_DIRECTION_BIT              MEGA2560 Digital Pin 30

 Y_DIRECTION_BIT              MEGA2560 Digital Pin 31

 Z_DIRECTION_BIT              MEGA2560 Digital Pin 32

 A_DIRECTION_BIT              MEGA2560 Digital Pin 33

 B_DIRECTION_BIT              MEGA2560 Digital Pin 34

 C_DIRECTION_BIT              MEGA2560 Digital Pin 35



 SPINDLE_PWM_BIT MEGA2560 Digital Pin 7

 SPINDLE_ENABLE_BIT        MEGA2560 Digital Pin 6

 SPINDLE_DIRECTION_BIT   MEGA2560 Digital Pin 5



  COOLANT_FLOOD_BIT       MEGA2560 Digital Pin 8

  COOLANT_MIST_BIT         MEGA2560 Analog Pin 8

  PIN_FEED_HOLD     1        MEGA2560 Analog Pin 9

  PIN_CYCLE_START  2        MEGA2560 Analog Pin 10

  PROBE_BIT             3        MEGA2560 Analog Pin 11
